JE 4G63 6-Bolt DSM Piston Rings
85.50 (JG2704-3366)
$172.88
Skip to product information
Vehicle Fitment:
6-Bolt 4G63 DSM
1990-1992.5 Eclipse, Talon & Laser Turbo
Description:
All rings are all included as a complete replacement set for 4 JE pistons. Please review specs and sizing below before purchase.
$172.88
6-Bolt 4G63 DSM
1990-1992.5 Eclipse, Talon & Laser Turbo
Description:
All rings are all included as a complete replacement set for 4 JE pistons. Please review specs and sizing below before purchase.
JE 4G63 6-Bolt DSM Piston Rings |
|||
Ring Spec: |
JG2704-3366 |
JG1004-3366 |
JG2804-3386 |
| Bore Size: | 85.50mm (3.366") | 85.50mm (3.366") | 86.00mm (3.386") |
| Oil Radial Width: | 0.117" | 0.128" | 0.105" |
| Oil Thickness: | 3.0mm | 2.8mm | 3.0mm |
| Oil Type: | CNS | CNF | CNS |
| Second Radial Width: | 0.155" | 0.142" | 0.155" |
| Second Thickness: | 1.5mm | 1.2mm | 1.5mm |
| Second Type: | IUU | DPE | IUQ |
| Top Radial Width: | 0.127" | 0.126" | 0.127" |
| Top Thickness: | 1.2mm | 1.0mm | 1.2mm |
| Top Type: | CNS | CNS | CNR |
